Mini-PCIe
slots
XH61V features two Mini PCI Express expansion slots:
1) half size, supports PCIe 2.0 and USB 2.0, e.g. for WLAN cards [5]
2) full size, supports PCIe 2.0, SATA 3G and USB 2.0
e.g. for Mini SATA (mSATA) flash memory cards [6]
Integrated
Graphics
The features of the integrated graphics function [3]
depends on the used processor type.
"Sandy Bridge" processor: Intel® HD Graphics 2000/3000, DirectX 10.1
"Ivy Bridge" processor: Intel® HD Graphics 2500/4000, DirectX 11
Maximum shared memory size: 1692MB
Supports HDMI, max. resolution up to 1920x1200 @ 60Hz
Supports DVI, max. resolution up to 1920x1200 @ 60Hz
Supports D-Sub, max. resolution up to 2048x1536 @ 75Hz
(optional VGA-to-DVI-adapter required)
Supports Blu-ray Stereoscopic 3D with HDMI 1.4a [1]
Supports HDCP function with DVI and HDMI ports
Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback with DVI and HDMI ports
Supports Dual-Independent-Display via HDMI and DVI-I port
HDMI supports HD video plus multi-channel digital audio via a single cable
Audio
Audio Realtek® ALC 662 6-channel High-Definition Audio
Three analog audio connectors (3.5mm) at the Back-Panel:
1) Front Line out (head phone)
2) Rear Surround line-out (shared with microphone input)
3) Center line-out (shared with Line in)
Digital audio output: S/PDIF (optical) and via HDMI
Mini-PCIe
slots
XH61V features two Mini PCI Express expansion slots:
1) half size, supports PCIe 2.0 and USB 2.0, e.g. for WLAN cards [5]
2) full size, supports PCIe 2.0, SATA 3G and USB 2.0
e.g. for Mini SATA (mSATA) flash memory cards [6]
Dual
Gigabit LAN
Controller
Dual Realtek 8111E Ethernet network controller (Gigabit)
Supports 10 / 100 / 1.000 MBit/s operation
With two RJ45 ports (dual network) supports Teaming [4]
Supports WAKE ON LAN (WOL)
Supports network boot by Preboot eXecution Environment (PXE)
Drive
Connectors
3x Serial-ATA II, 3 Gb/s (300 MB/s) bandwidth
Supports Unified Extensible Firmware Interface (UEFI) [2]
Note: This barebone system comes with two pre-installed SATA cables:
for one 2.5" hard disk and for one optical slim drive.
Front Panel
Connectors
Microphone input, Audio Line-out (headphone)
2x USB 2.0
Power button
Power LED (blue), HDD LED (yellow)
