Before attempting the connection,
check whether the voltage indicated
on the rating plate corresponds to
the actual mains voltage.
Mains lead should be minimum1.5m
long.
Earthing wire should be installed in
such manner to be the last one pulled
out in case the safety relief device of
the mains lead should fail.
Mains lead behind the oven must be
placed in such manner to avoid
touching the back panel of the oven
because of the heat it develops
during operation.
The cable of corroct size rating must
1.5m .
2
m
-
zzzz
(by authorised electrician)
5
4
2
5
4
2
the grounding wire shall be
longer than the other wires.
The means for disconnection from
the supply mains having a contact
separation in all poles that provide
full disconnection under over voltage
category iii shall be provided in the
fixed wiring in accordance with the
wiring rules.
