7
THE FINISHED ASSEMBLY INSIDE THE CISTERN
MAINTENANCE
Servicing the valve
To access the valve, unscrew
the assembly as shown.
(2)
(1)
For further enquiries
Contact Customer Services PJH on 0161 703 3360
1
To change the diaphragm washer inside the inlet valve
Turn off the water supply to the inlet valve.
Unscrew the knurled nut at the top of the
inlet valve
Remove the black rubber diaphragm
washer
Insert the replacement washer
Screw the nut back onto the inlet valve,
ensuring that the lift arm is holding the
float valve correctly
Turn the water supply back on
1
2
3
4
5
6
3
4
