Sices DST4601 - 2.3 Signals Description

8 User’s Manual
Signals
Function
EMERGENCY STOP
Signals the EMERGENCY STOP command activation. If flashing, the
status isn’t already acknowledged (it is to press the MODE/ACK
pushbutton).
ALARM
Signal a BLOCK or a DISABLE. If flashing, the status isn’t already
acknowledged (it is to press the MODE/ACK pushbutton).
WARNING
Signal a WARNING. If flashing, the status isn’t already acknowledged (it is
to press the MODE/ACK pushbutton).
GEN-SET VOLTAGE
If ON, the MEASURES display is showing the phase-to-phase genset
voltages.
If flashing it is showing the phase to neutral voltages.
GEN-SET CURRENT
If ON, the MEASURES display is showing the genset phase currents.
MAINS-VOLTAGE
If ON, the MEASURES display is showing the phase-to-phase mains
voltages.
If flashing indicates that the inhibition input (MAINS SIMULATION) is
active.
ACTIVE POWER
If ON, the MEASURES display is showing the genset phase active
powers.
BATT./SPEED/FREQ.
If ON, the MEASURES display is showing the battery voltage (L1), the
engine speed (L2) and the genset frequency (L3).
GEN-SET VOLTAGE
GEN-SET CURRENT
BATT./SPEED/FREQ.
All flashing
The display is showing the phase-to-phase genset voltage (L1), the
genset phase current (L2) and the genset frequency (L3). Every 4
seconds is changed the displayed phase.
TEST
ON or FLASHING: if in TEST mode.
FUEL PUMP
OFF: fuel pump command in manual and inactive.
ON: fuel pump command in automatic and inactive.
FLASHING: fuel pump command in automatic or manual and active.
REMOTE LINK
ON if the board is connected by the RS232 port to an external
communication device (modem, PC etc.)
PROGRAM
MULTIFUNCTION display is in PROGRAM mode.
STATUS
MULTIFUNCTION display is in STATUS mode. FLASHING: there is a
remote start command or a changeover inhibition command pending.
MEASURES
MULTIFUNCTION display is in MEASURES mode.
EVENTS LOG
MULTIFUNCTION display is in EVENTS LOG mode.
MAINS LIVE
OFF if MAINS is not present.
ON if MAINS voltages fall into the working threshold levels.
Flashing if MAINS is present but outside the working windows.
MCB
“Mains circuit breaker”.
OFF if open, ON if closed.
Flashing 25% ON and 75% OFF if open while it is driven to close.
Flashing 75% ON and 25% OFF if closed while it is driven to open.
GCB
“Generator circuit breaker”.
OFF if open, ON if closed.
Flashing 25% ON and 75% OFF if open while it is driven to close.
Flashing 75% ON and 25% OFF if closed while it is driven to open.
GENERATOR LIVE
OFF if generator voltages are not present.
ON if GENERATOR voltages fall into the working threshold levels.
Flashing if GENERATOR is present but outside the working windows.
ENGINE RUNNING
OFF if engine is dead.
ON if engine is running.
Flashing if cooling down.
