System connection pin assignment (male connector, M12, 5-pin)
Pin Wire color
1)
s S
ender r Receiver
1 Brown +24VDC (voltage supply
in
put)
+24VDC (voltage supply
input)
2 White Reserved OSSD1 (output signal
switching device 1)
3 Blue 0VDC (voltage supply
input)
0VDC (voltage supply
input)
4 Black Reserved OSSD2 (output signal
switching device 2)
5 Gray Not connected Not connected
1)
Applies to the connecting cables recommended as accessories.
A
1
PWR
2
ERR
B
1
O
SSD
2
ERR
3
1
2 3
4
C
1
3
4
2
a
b
a
b
D
1
2
3
MOUNTING INSTRUCTIONS
8025628/1HLF/2022-11-03 | SICK M O U N T I N G I N S T R U C T I O N S | C4-RD
17
Subject to change without notice
en
