Siebert Series S102 - Page 24

24 BAL S102 ANA M 1.0
Block diagrams
Units with 14 mm character height
PE
22
C6 C4 C3 C2 C1C5
100k
+U +I GND Tx+ Tx- M F CO2 NO2 CO1 NO1 0 V 24 V
Signal input
Power
supply
Switching outputs
Output 2
Output 1
Hold
RS422
5k4
Units with 25 mm character height
PE
22
100k
+U +I GND Tx+ Tx- M F CO2 NO2 CO1 NO1 M P
Signal input
Sensor
power
supply
Switching outputs
Output 2 Output 1
Hold
RS422
C4 C3 C2 C1C5
24 V0 V
Power
supply
5k4
