BAL S102 ANA M 1.0 23
ENGLISH
These operating instructions are valid for units with the following type code:
S102-x6/14/0x-00x/0B-A0 Character height 14 mm, 6 digits
S102-x5/25/0x-00x/0B-A0 Character height 25 mm, 5 digits
The 'x's in the model designation indicate the size and design of the units (see
‘Technical data’).
Dimensions
Units with 14 mm character height
Units with 25 mm character height
