BAL S102 ANA M 1.0 29
Canceling the menu without saving the settings made is possible by pressing both
menu buttons simultaneously (approx. 1 sec.) or will happen automatically if 60
seconds pass without a menu button being pressed.
Once the menu is closed, the unit behaves in the same manner as after power-on.
In menu mode, a control of the unit is not possible.
The menu items are listed in the following table. Default settings are marked with *.
Individual menu items or settings may be suppressed in another menu item
depending on the type of unit or setting.
Menu item Settings Display
1 Input signal 0…20 mA*
1 0-20
4…20 mA
1 4-20
0…10 V
1 0-10
2…10 V
1 2-10
2
Min. value
-99999…000000*…999999
1)
2 000000
-9999…00000*…99999
2)
2 00000
3
Max. value
-99999…000000…999999
1) 3)
3 000000
-9999…00000…99999
2) 3)
3 00000
4
Step width
1* (digit C1 = 0…9)
4 1
5 (digit C1 = 0/5)
4 5
10 (digit C1 = 0)
4 10
50 (digit C2 = 0/5, digit C1 = 0)
4 50
100 (digit C2 = 0, digit C1 = 0)
4 100
5
Average value
No averaging*
5 1
Average value over 2 intervals
5 2
Average value over 4 intervals
5 4
Average value over 8 intervals
5 8
1)
Applies for units with 6 digits (S102-x6/14/0x-00x/0B-A0)
2)
Applies for units with 5 digits (S102-x5/25/0x-00x/0B-A0)
3)
Factory setting: 10000
