Parts list (4) --- note: The no. With “*” means the part showing in metric.
Part No. Drawing No. Description Q'ty
.4-1 X31136 The left bracket cover 1
.4-2 XN3A1106 Left cover 1
.4-3 X31131 Longitudinal leadscrew rod bracket left sleeve 1
.4-4 XN3A1102 Work table 1
.4-5* XN3A1113A Metric longitudinal leadscrew nut 1
.4-6 XN3A1103 Saddle 1
.4-7 XN3A1101 Base 1
.4-8 X3111800 Handwheel 2
.4-9 XN3A1105 Cross bevel wedge 1
.4-10 XN3A1109 Longitudinal wedge locking crown bar 1
.4-11 X2021800 Small handle assembly 2
.4-12* XN3A1110A Metric longjitudinal leadscrew 1
.4-13 XN3A1108 Longitudinal\cross leadscrew bearing seat 2
.4-14* XN3A1112A Metric longitudinal/cross scale dial 2
.4-15 GB 6172-86 M8 Hexagon nut M8 2
.4-16 GB 70-85 - M5 x 14 Hexagon socket head cap screw M5*14 2
.4-17 X31144 Plug 1
.4-18 GB 70-85 - M6 x 16 Hexagon socket head cap screw M6*16 6
.4-19 GB1096-79 4x16 Parallet key 4*16 2
.4-20 GB 889-86 M8 Hexagon locking nut M8 2
.4-21 GB 65-85x55 Slotted large cheese head screws 85*55 2
.4-22 X31145 Sping piece 2
.4-23 GB 301-84 - 8101 Thrust ball bearing 8101 4
.4-24 XN3A1111 Longjitudinal bevel wedge 1
.4-25* XN3A1107A Metric cross leadscrew nut 1
.4-26* XN3A1104A Metric cross leadscrew 1
.4-27 GB 70-85 - M5 x 20 Hexagon socket head cap screw M5*20 2
.4-28 C2A0307 Handle 2
.4-29 XN3A0217 Tighten the top rod 1
.4-30 JBT7940.4-95 6 Pressure with pressure column oil cup 6 1
.4-31 GB 70-85 - M4 x 14 Hexagon socket head cap screw M4*14 4
.4-32 XN3A0223 Wedge screw 4
.4-33 GB 119-86 - A 4 x 20 Round pin A4*20 6
.4-34 XN3A1114 Scale height 1
.4-35 GB827-86 2x3 Label rivet 2*3 4
.4-36 C5C0315 Zero lebel 1
.4-37 GB 97.1-85 - 8 Washer 8 2
4-38 GB 117-86 - A 3 x 30 Taper pin A3*30 2
4-39 GB 70-85 - M6 x 10 Hexagon socket head cap screw M6*10 1
4-40 GB 96-85 - 6 Washer 6 1
4-41 GB 117-86 - B 3 x 26 Taper pin B3*26 2
