Parts list ( 1 / MT3 ) --the spindle taper is MT3
Part No. Drawing No. Description Q'ty
.1-1 XN3A0201 Spindle box 1
.1-2 GB 818-85 - M4 x 6 Cross recessed small pan head screw H M3*8 4
.1-3 X3C0219 Spindle below oil seal ring I 1
.1-4 X20206 B16 taper shank 1
.1-5 GB/T 297-94 - 32907 Cone roller bearing 32907 1
.1-6 GB 6172-86 - M5 Hexagon headed nut M5 2
.1-7 XN3A0218 Fine feeding handwheel 1
.1-8 X3C0217 Display square screw 1
.1-9 X3C0216 Spindle sleeve below oil seal ring II 1
.1-10 GB 818-85 - M3 x 8 Cross recessed small pan head screw Z M3*8 12
.1-11 XN3A0215 Base plate 1
.1-12 GD300-165 Display assembly 1
.1-13 XN3A0207 Panel 1
.1-14 X3C0210 Up washer II 1
.1-15 GB 819-85 - M5x25 Cross recessed counter head screws H M5*25 1
.1-16 XN3A0210 Bevel gear 1
.1-17 XN3A0204 Gear shaft 1
.1-18 XN3A0212 Handle seat 1
.1-19 GB 894.1-86 16 Check ring 16 1
.1-20 XN20243 Clock spring 1
.1-21 X3C0253 Clock spring cover 1
.1-22 XN3A0205 Pindle box cover 1
.1-23 X3C0208 Bearing seat 1
.1-24 X3C0206 Spindle timing pulley 1
.1-25 XN3A0219 Motor timing pulley 1
.1-26 X30252 Handle lever 3
.1-28 X2021800 Small handle assembly 1
.1-29 X20237 Long handle sleeve 3
.1-30 XN3A0208 Spindle sleeve locking shaft 1
.1-31 XN3A0217 Tighten the top rod 1
.1-32 GB 79-85 - M6 x 14 Slotted headless set screws round end M6*14 1
.1-33 GB 77-85 - M6 x 8 Inner six angle fastening screws-flat end M6*8 1
.1-34 GB308-89 - 8 Ball 8 3
.1-35 XN3A0224 Locking small shaft 1
.1-36 X3C0238 Worm gear locking handle 1
.1-37 X3C0213 Spindle sleeve 1
.1-38 X3C0252 Shaft gear left support flange 1
.1-39 GB 77-85 - M6 x 10 Inner six angle fastening screws-flat end M6*10 1
.1-40 XN3A0221 Shaft gear right support flange 1
.1-41 GB1096-79 4x8 Parallel key 4*8 1
.1-42 X3C0220 Spindle up dust guard I 1
.1-43 X3C0265 Spindle up dust guard II 1
.1-44 GB 70-85 - M4 x 10 Hexagon round head cap screw M4*10 3
.1-45 XN3A0216 Eccentric sleeve locking block 1
