Sieg X2.7 - Installation and Specifications; Grounding Instructions; Machine Specifications; Unpacking and Preparation

3
IF THERE IS ANY QUESTION ABOUT A CONDITION BEING SAFE OR UNSAFE,
DO NOT OPERATE THE TOOL!
Grounding Instructions
This machine has a three-prong plug, the third prong is the ground. Plug this cord
only into a three-prong receptacle. Do not attempt to defeat the protection the ground wire
provides by cutting off the round prong. Cutting off the ground will result in a safety hazard
and void the warranty.
DO NOT MODIFY THE PLUG IN ANY WAY. IF YOU HAVE ANY DOUBT, CALL A
QUALIFIED ELECTRICIAN.
Specification：
Max. drilling capacity:
20 mm
End mill capacity
16 mm
Face mill capacity
50 mm
Throat
190 mm
Max. distance spindle to table
370 mm
Spindle taper
MT#3 or R8
Spindle speed
100-2500 rpm ±10%
Table effective size
600x140 mm
T-slot size
12 mm
Table longitudinal travel (X)
400 mm
Cross travel (Y)
190 mm
Headstock travel (Z)
290 mm
Power
750 W
Overall dimension (L*W*H)
725*620*880 mm
Packing size (L*W*H)
840*760*1060 mm
Weight (Net/Gross)
101 / 135 Kg
Unpacking & Preparing for Use
Before unpacking you must check the package carefully, to find whether it is damaged
and any may have effect on the machine, please connect with the distributor in advance.
Unpacking carefully, check the species of standard accessories and the quantity to find
whether it is as same as the packing list in the package.
