Parts list ( 5 ) (Note: some type without the protective guard assembled)

Part No. Drawing No. Description Q'ty

.5-1 XN3A2305 Splash guard I 1

.5-2 XN3A2304 Splash guard II 1

.5-3 X20002 Filler strip 1

.5-4 GB 818-85 - M4*6 Cross recessed counter head screws M5*6 6

.5-5 X20003 Dust guard 1

.5-6 X20004 Dead plate 1

.5-7 GB 818-85 - M4*10 Cross recessed counter head screws M4*10 2

.5-8 XN3A2302 Rise and down guideway cover 1

.5-9 YE023003 Ø6 Magnet steel 5

.5-10 XN3A2303 Shield baffle 1

.5-11 GB 819-85 - M4x10 Cross recessed counter head screws M4*10 3

.5-12 X3C23C0401 The inner shield 1

.5-13 GB 835-88 - M5x20 Knurled screws M5*20 2

.5-14 GB 97.1-85 - 5 Washer 5 2

.5-15 X3C23C03 Outer protective cover 1

.5-16 GB 70-85 - M4 x 10 Hexagon socket head cap screw M4*10 1

.5-17 X12304 Block 1

.5-18 XN3A2301 Connecting plate 1

.5-19 QKS7-5 Safety limit switch 1

.5-20 GB 889-86 - M6 Hexagon locking nut M6 1

.5-21 GB 96-85 - 6 Washer 6 1

.5-22 X3C23C01 Support plate 1

.5-23 GB 70-85 - M4 x 12 Hexagon socket head cap screw M4*12 3

.5-24 X3C23C05 Spacer bush 1

.5-25 GB 818-85 - M4 x 25 Cross recessed counter head screws M4*25 2

.5-26 GB 78-85 - M4 x 6 Inner six angle locking screw-cone end metric M4*6 1

.5-27 X3C23C02 Rotate shaft 1
