Sieg X2.7 - Page 21

21
Parts list ( 6 )
Part No. Drawing No. Description Q'ty
.6-1 GB 846-85 - ST2.9 x 9.5 Tapping screw 4
.6-2 ZH-A Change-over switch 1
.6-3 HY57B Emergency stop 1
.6-4 M14 Lampholder 1
.6-5 RSD-27 Digital readout 1
.6-6 WH24-1 4.7K Potentionmeter 1
.6-7 φ23 Knob 1
.6-8 XN3A1802 Electric box cover 1
.6-9 GB 845- ST2.2 x 6.5 Tapping screw 4
.6-10 GB 6170-86 - M4 Hexagon headed nut M4 7
.6-11 GB 5781-86 - M4x16 Hexagon headed bolt M4*16 3
.6-12 DYB-01 Power panel 1
DYB-01 Power panel 1
.6-13 XN3A1801 Electric box 1
.6-14 WQG-M30B/AD28.5
Tube connecter
2
.6-15 WY-PP AD28.5
Tube
1
.6-16 GB 819-85 - M3x12 Cross recessed counter head screws M3*12 2
.6-17 DB-14F Power socket 1
.6-18 GB 6170-86 - M3 Hexagon headed nut M3 2
.6-19 XN3A180300
Back cover
1
.6-20 GB 818-85 - M3 x 12 Cross recessed small pan head screw M3*12 4
.6-21 CJ9525B18102 Foot-pad 4
.6-22 XMT-2375 PC board 1
XMT-1175 PC board 1
.6-23
XN3A1804
Back cover
1
.6-24
GB 818-85 - M4 x 8
Cross recessed small pan head screw M4*8
6
.6-25 GB 93-87 - M5
Spring spacer
4
.6-26
GB 818-85 - M5 x 6
Cross recessed small pan head screw M5*6
4
.6-27
X3C1802
Grounding bar
1
.6-28
X3C1806
Blow dust gauze
1
.6-29
GB 97.1-85 - 4
Washer
4
