Siemens ST 80 · 2006
2/120
Operator Control and Monitoring Devices
SIMATIC OP 270
Panels — 270 series
2
■ Function (continued)
Configuration
Configuring is performed using the configuring software SI-
MATIC ProTool or SIMATIC ProTool/Pro Configuration (see HMI
software/configuring software or visualization software) or using
the engineering software SIMATIC WinCC flexible Standard or
Advanced (see HMI software/SIMATIC WinCC flexible engineer-
ing software).
Projects generated using ProTool can be imported into WinCC
flexible.
Applications/options
When configuring with ProTool
• SIMATIC ProAgent/MP;
fast, localized fault diagnosis in plants and machines for
SIMATIC S7 and SIMATIC HMI (see HMI software/process
diagnostics software SIMATIC ProAgent)
When configuring with WinCC flexible
• WinCC flexible /ProAgent;
fast, localized fault diagnosis in plants and machines for
SIMATIC S7 and SIMATIC HMI (see HMI software/process
diagnostics software SIMATIC ProAgent)
• WinCC flexible /Sm@rtAccess;
Remote control and monitoring as well as communication be-
tween different SIMATIC HMI systems (see WinCC flexible RT
options)
• WinCC flexible /Sm@rtService;
Remote monitoring and service of machines/plants over the
Internet/Intranet (see WinCC flexible RT options)
■ Integration
The SIMATIC OP 270 Operator Panels can be connected to:
• SIMATIC S7-200/-300/-400
• SIMATIC WinAC Software/Slot PLC
• SIMATIC S5
• SIMATIC 505
•SINUMERIK
•SIMOTION
• Non-Siemens PLCs
- Allen Bradley
- Mitsubishi
- Telemecanique
1)
- LG GLOFA GM
- Modicon
- GE-Fanuc
-Omron
• Over Ethernet (TCP/IP) to higher-level PC and network printer
(optionally over NE2000-compatible network card)
Additionally when configuring with WinCC flexible
• Ethernet communication with SIMATIC S7
(optionally over NE2000-compatible network card)
• Multi-protocol capability
• HTTP communication to other SIMATIC HMI systems
(optionally with the "WinCC flexible /Sm@rtAccess" option)
•SINUMERIK
(optionally with "SINUMERIK HMI copy license
WinCC flexible CE"; the "SINUMERIK HMI engineering pack-
age WinCC flexible" is additionally necessary for configuration;
for further information, see Catalog NC 60)
1) Cannot be connected in conjunction with WinCC flexible
Note:
For further information, see "System interfaces".
© Siemens AG 2007
