Siemens ST 80 · 2006
2/113
Operator Control and Monitoring Devices
Panels — 270 series
SIMATIC TP 270
2
■ Technical specifications
SIMATIC
TP 270
5,7“ Color
STN Display
SIMATIC
TP 270
10,4“ Color
STN Display
Display
• Display type STN liquid
crystal display
(LCD)
STN liquid
crystal display
(LCD)
•Size
5.7" 10.4"
• Resolution (W x H in pixels)
320 x 240 640 x 480
• Colors
256 colors 256 colors
• MTBF of background lighting
(at 25 °C)
approx.
40,000 hours
approx.
60,000 hours
Operating mode
• Control elements Touch screen Touch screen
• Operating options
Touch Touch
• Touch screen
Analog,
resistive
Analog,
resistive
• Numeric/alphanumeric input
Yes/Yes Yes/Yes
• External mouse/keyboard/
barcode reader
USB/USB/USB USB/USB/USB
Processor/HW
RISC 32 bits,
180 MHz
RISC 32 bits,
180 MHz
Operating systems
Windows CE Windows CE
Memory
• Type Flash/RAM Flash/RAM
• Usable memory for project data
2028 KB user
memory/with-
out additional
memory for
options
2028 KB user
memory/with-
out additional
memory for
options
Interfaces (some only as options)
• Interfaces 2 x RS232,
1 x RS422,
1 x RS485
max. 12 Mbit/s
2 x RS232,
1 x RS422,
1 x RS485
max. 12 Mbit/s
• CF card slot
1 x CF card slot 1 x CF card slot
• USB (universal serial bus)
1 x USB 1 x USB
Supply voltage
• Supply voltage 24 V DC 24 V DC
• Permissible range
+18 to
+30 V DC
+18 to
+30 V DC
• Rated current
0.6 A 0.6 A
•Output
15 W 15 W
• UPS can be connected (serial)
Yes Yes
• Backup battery
Optional 3.6 V Optional 3.6 V
Clock
Hardware
clock, battery-
backed and
synchronized
Hardware
clock, battery-
backed and
synchronized
Degree of protection
• Front IP65, NEMA 4,
NEMA 4x,
NEMA 12;
(when
mounted)
IP65, NEMA 4,
NEMA 4x,
NEMA 12;
(when
mounted)
• Rear
IP20 IP20
Certification
(some only as options)
CE, GL, ABS,
DNV, LRS, FM
Class I Div. 2,
UL, cULus,
EX zone 2/22,
C-TICK
CE, GL, ABS,
DNV, LRS, FM
Class I Div. 2,
UL, cULus,
EX zone 2/22,
C-TICK
SIMATIC
TP 270
5,7“ Color
STN Display
SIMATIC
TP 270
10,4“ Color
STN Display
Mechanical components/
dimensions
• Front panel W x H (mm) 212 x 156 335 x 275
• Mounting cutout/depth W x H x D
(mm)
198 x 142/
59 mm depth
of unit
310 x 248/
59 mm depth
of unit
•Weight
1 kg 4.5 kg
Ambient conditions
• Max. relative humidity (in %) 85% 85%
• Mounting position
Vertical Vertical
- Max. permissible angle of
inclination without external fan
+/- 35° +/- 35°
•Temperature
- Operation (vertical installation)
0 to +50 °C 0 to +50 °C
- Operation
(max. angle of inclination)
0 to +35 °C 0 to +40 °C
- Transportation and storage
-20 to +60 °C -20 to +60 °C
Expansions for operator-process
communication
(may only be an option)
• DP direct keys (buttons as input
peripherals)
4 bytes or
coded
5 bytes or
coded
Peripherals/applications/options
•I/O Printer, bar-
code reader
Printer, bar-
code reader
• Applications/options
(with ProTool)
ProAgent ProAgent
Configuring
• Configuration tool ProTool ProTool
• Configuration tool
WinCC flexible WinCC flexible
Functionality
(with WinCC flexible)
• Scheduler Yes Yes
• Help system
Yes Yes
• Status/Control
with SIMATIC
S5/S7
with SIMATIC
S5/S7
Protocols
• Interface to control
(may only be an option)
S5, S7-200,
S7-300/400,
505Win AC,
PC (TCP/IP),
SINUMERIK,
SIMOTION,
Allen Bradley
(DF1),
Allen Bradley
(DF485),
Mitsubishi (FX),
Telemecanique
(ADJUST),
OMRON
(LINK/Multi-
link), Modicon
(Modbus)
and other
non-Siemens
drivers
S5, S7-200,
S7-300/400,
505Win AC,
PC (TCP/IP),
SINUMERIK,
SIMOTION,
Allen Bradley
(DF1),
Allen Bradley
(DF485),
Mitsubishi (FX),
Telemecanique
(ADJUST),
OMRON
(LINK/Multi-
link), Modicon
(Modbus)
and other
non-Siemens
drivers
