Siemens 270 series User Manual

Siemens ST 80 · 2006
2/114
Operator Control and Monitoring Devices
SIMATIC TP 270
Panels — 270 series
2
■ Technical specifications (continued)
SIMATIC
TP 270
5,7“ Color
STN Display
SIMATIC
TP 270
10,4“ Color
STN Display
Functionality
(with WinCC flexible) (continued)
Signaling system
• Number of messages 4000 4000
• Discrete alarms
Yes Yes
• Analog messages
Yes Yes
• Message length (in characters)
70 70
• Number of process values per
message
8 8
• Acknowledgement groups
99 99
• Message buffer
Ring buffer, 512
entries each
Ring buffer, 512
entries each
Recipes
• Recipes 300 300
• Data records per recipe
500 500
• Entries/data record
1000 1000
• Recipe memory
64 KB inte-
grated Flash,
expandable
64 KB inte-
grated Flash,
expandable
Process images
300 300
Picture elements
• Text objects 10,000 text ele-
ments
10,000 text ele-
ments
• Fields per screen
200 200
• Variables/screen
200 200
• Graphics objects
Bitmaps, icons,
vector graphics
Bitmaps, icons,
vector graphics
• Dynamic objects
Diagrams, hid-
den buttons
Diagrams, hid-
den buttons
Variables
2048 2048
Archiving
• Number of archives per project 20 20
• Number of process tags
per archive
0 0
• Number of entries per archive
10,000 10,000
• Archive types
Sequence
archive, short-
term archive,
alarm log,
process value
archive
Sequence
archive, short-
term archive,
alarm log,
process value
archive
• Memory location
CF card,
Ethernet
CF card,
Ethernet
• Data storage format
CSV file, can be
read, e.g., in
MS Excel, MS
Access
CSV file, can be
read, e.g., in
MS Excel, MS
Access
• External evaluation
Can be read,
e.g., in MS
Excel, MS
Access, etc.
Can be read,
e.g., in MS
Excel, MS
Access, etc.
• Size of archive
Dependent on
the memory
space avail-
able on the
external
card/stick or
spare hard disk
memory via the
network drive
Dependent on
the memory
space avail-
able on the
external
card/stick or
spare hard disk
memory via the
network drive
• Online evaluation
Using trend
curves
Using trend
curves
SIMATIC
TP 270
5,7“ Color
STN Display
SIMATIC
TP 270
10,4“ Color
STN Display
Functionality
(with WinCC flexible) (continued)
Security
• Number of user groups 10 10
• Exportable passwords
Yes Yes
Visual Basic Script
not possible not possible
Logging/printer driver
• Printing/logging Messages,
report/log,
color print
Messages,
report/log,
color print
• Printer driver
ESC/P2,
PCL3/PCL6
ESC/P2,
PCL3/PCL6
Fonts
• Keyboard fonts US English US English
Languages
• Online languages 5 5
• Project languages:
D, GB, F, I, E,
CHN "tradi-
tional", CHN
"simplified", DK,
FIN, GR, J,
KP/ROK, NL, N,
PL, P, RUS, S,
CZ/SK, TR, H
D, GB, F, I, E,
CHN "tradi-
tional", CHN
"simplified", DK,
FIN, GR, J,
KP/ROK, NL, N,
PL, P, RUS, S,
CZ/SK, TR, H
• Character sets
Tahoma,
ideographic
languages,
2 further char-
acter sets can
be loaded, all
freely scalable
Tahoma,
ideographic
languages,
2 further char-
acter sets can
be loaded, all
freely scalable
Data carrier support
(may only be an option)
• CF card Yes Yes
• Applications/options
(with WinCC flexible)
ProAgent ProAgent
Transfer under ProTool
(upload/download)
• Transfer of the configuration MPI/PROFIBUS
DP, serial, USB,
Ethernet (auto-
matic transfer
recognition)
MPI/PROFIBUS
DP, serial, USB,
Ethernet (auto-
matic transfer
recognition)
© Siemens AG 2007
