Siemens ST 80 · 2006
2/116
Operator Control and Monitoring Devices
SIMATIC TP 270
Panels — 270 series
2
■ Ordering data Order No. Order No.
B) Subject to export regulations AL: N and ECCN: 5D002ENC3
D) Subject to export regulations AL: N and ECCN: 5D992B1
SIMATIC TP 270
Touch Panel with
• 5.7" color STN display
B
6AV6 545-0CA10-0AX0
• 10.4" color STN display
B
6AV6 545-0CC10-0AX0
incl. mounting accessories
Configuring
with SIMATIC ProTool
and ProTool/Pro
See Section 4
with SIMATIC WinCC flexible See Section 4
Configuration set
D
6AV6 622-0BA01-0AA0
Consisting of:
• WinCC flexible Standard
engineering software
• SIMATIC HMI Manual
Collection (CD),
5 languages (English, French,
German, Italian, Spanish)
• Configuration cable USB
master-master between PG/PC
and panel
• MPI cable, 5 m
Applications/options
When configuring with ProTool
• SIMATIC ProAgent/MP
See Section 4
When configuring with WinCC flexible
• WinCC flexible /ProAgent
See Section 4
• WinCC flexible /Sm@rtAccess See Section 4
• WinCC flexible/Sm@rtService See Section 4
Documentation (to be ordered separately)
Operating Instructions
TP 270/OP 270 and MP 270B
(WinCC flexible)
•German 6AV6 691-1DD01-0AA0
•English 6AV6 691-1DD01-0AB0
• French 6AV6 691-1DD01-0AC0
•Italian 6AV6 691-1DD01-0AD0
• Spanish 6AV6 691-1DD01-0AE0
User Manual
WinCC flexible
Compact/Standard/Advanced
•German 6AV6 691-1AB01-0AA0
•English 6AV6 691-1AB01-0AB0
• French 6AV6 691-1AB01-0AC0
•Italian 6AV6 691-1AB01-0AD0
• Spanish 6AV6 691-1AB01-0AE0
User Manual
WinCC flexible Communication
•German 6AV6 691-1CA01-0AA0
•English 6AV6 691-1CA01-0AB0
TP/OP 270 and MP 270B
(ProTool) Manual
•German 6AV6 591-1DC20-0AA0
•English 6AV6 591-1DC20-0AB0
• French 6AV6 591-1DC20-0AC0
•Italian 6AV6 591-1DC20-0AD0
• Spanish 6AV6 591-1DC20-0AE0
ProTool User Manual
for configuring Windows-based
systems
•German 6AV6 594-1MA06-1AA0
•English 6AV6 594-1MA06-1AB0
• French 6AV6 594-1MA06-1AC0
•Italian 6AV6 594-1MA06-1AD0
• Spanish 6AV6 594-1MA06-1AE0
© Siemens AG 2007
