Siemens 3AD8 User Manual

KMS-0021
9
2022-02-10
Abbreviations
CMR
Compact Modular Recloser
FS
Fusesaver
HV
High Voltage
IEC
International Electrotechnical Commission
LED
Light Emitting Diode
LV
Low Voltage
MLFB
Maschinenlesbare Fabrikatenummer (order number)
MV
Medium Voltage
PC
Personal Computer
RCU
Remote Control Unit
SCADA
Supervisory Control and Data Acquisition
USB
Universal Serial Bus
UTC
Universal Time Coordinated
VT
Voltage Transformer
References
[1] SMG-0087 CMR DNP3 Protocol Manual
[2] CMR-7001 Compact Recloser Configuration Manual
[3] RCU-CMR Pairing and Communication Manual
[4] RCU Operator Panels for CMR
[5] RCU Firmware Update
[6] KMS-0017 - Fusesaver Operating Instructions
[7] CMR-7000 Compact Recloser Installation Manual
[8] SMG-0054 Fusesaver DNP3 Protocol Manual
[9] SMG-0086 Fusesaver IEC-104 Protocol Manual
[10] SMG-0088 CMR IEC-104 Protocol Manual

Siemens 3AD8 Specifications

General

Brand	Siemens
Model	3AD8
Category	Control Unit
Language	English
