Siemens 3TF30 - Auxiliary Circuit Data; Auxiliary Circuit Ratings; Auxiliary Contact Block Ratings; Auxiliary Circuit Short-Circuit Protection

3
Short>circuit protection:
> Fuse>links
NEOZED and DIAZED, gL (gG) A 16
> Circuit>breaker, C>char. A 16
Auxiliary contact block 3TX40
Short>circuit protection:
> Fuse>links
NEOZED and DIAZED, gL (gG) A 16
> Circuit>breaker, C>char. A 10
Fig. A
For further data and accessories see Catalog NSK.
** Footnote:
According to IEC 60947/VDE 0660, the types of protection mean:
∫Assignment type 1∫: Short circuits can cause damage to the contactors making replacement of the equipment necessary
∫Assignment type 2∫ : Easily separable contact welding but no other damage
Rated operational voltage
Rated operational
current I
e
/AC>15/AC>11
> 230 V
> 400 V
> 500 V
> 690 V
A
A
A
A
5.6
3.8
2.5
1.8
Rated operational voltage
Rated operational
current I
e
/DC>13/DC>11
> 24 V
> 48 V
> 110 V
> 220 V
> 440 V
> 600 V
A
A
A
A
A
A
10
4.6
0.8
0.2
0.11
0.08
Auxiliary circuit
Rated operational voltage
Rated operational
current I
e
/AC>15/AC>11
> 230 V
> 240 V
> 400 V
> 415 V
> 500 V
> 690 V
A
A
A
A
A
A
10
10
6
4
4
2
Rated operational voltage
Rated operational
current I
e
/DC>13/DC>11
> 24 V
> 48 V
> 110 V
> 220 V
> 440 V
> 600 V
A
A
A
A
A
A
10
5
0.9
0.45
0.25
0.2
CIRCUIT
PROTECTIVE
DEVICE
(IF USED)
L1
L2
L3
FUSE
M
M
M
OLR
OLR
OLR
T1
T2
T3
3
PHASE
MOTOR
FUSE
FUSE
X1
H4
X2
H1
PRI.
SEC.
M
STOP
(1)
START
44
(2)
43
(3)
95 96
M
A1 A2
2 WIRE CONTROL (IF USED)
OLR
IF CPT IS
USED
