Siemens 6SL3352-7AE32-1AA1 Quick Start Guide

Issue 08/03
14 Quick Start Guide MICROMASTER 440
6SE6400-5GA00-0BP0
1.2 Environment, Heat Loss and Air Flow
These figures should be used when mounting MICROMASTER 440s into enclosures.
Figures shown are for unfiltered units. You can assume that the filtered versions of these drives
(where available) have similar figures.
Drive Part
Number.
Heat
Loss (W)
Clearance Required
Above Drive – Inches
(mm)
Clearance Required
Below Drive – Inches
(mm)
Air Flow -
CFM (m
3
/min)
1ph 230V Input
6SE6440-2UC11-2AA1 5 4” (100mm) 4” (100mm) 10.2 (0.29)
6SE6440-2UC12-5AA1 10 4” (100mm) 4” (100mm) 10.2 (0.29)
6SE6440-2UC13-7AA1 15 4” (100mm) 4” (100mm) 10.2 (0.29)
6SE6440-2UC15-5AA1 22 4” (100mm) 4” (100mm) 10.2 (0.29)
6SE6440-2UC17-5AA1 30 4” (100mm) 4” (100mm) 10.2 (0.29)
6SE6440-2UC21-1BA1 39 4” (100mm) 4” (100mm) 51 (1.44)
6SE6440-2UC21-5BA1 53 4” (100mm) 4” (100mm) 51 (1.44)
6SE6440-2UC22-2BA1 77 4” (100mm) 4” (100mm) 51 (1.44)
6SE6440-2UC23-0CA1 90 4” (100mm) 4” (100mm) 116 (3.28)
3ph 230V Input
6SE6440-2UC11-2AA1 5 4” (100mm) 4” (100mm) 10.2 (0.29)
6SE6440-2UC12-5AA1 10 4” (100mm) 4” (100mm) 10.2 (0.29)
6SE6440-2UC13-7AA1 15 4” (100mm) 4” (100mm) 10.2 (0.29)
6SE6440-2UC15-5AA1 22 4” (100mm) 4” (100mm) 10.2 (0.29)
6SE6440-2UC17-5AA1 30 4” (100mm) 4” (100mm) 10.2 (0.29)
6SE6440-2UC21-1BA1 39 4” (100mm) 4” (100mm) 51 (1.44)
6SE6440-2UC21-5BA1 53 4” (100mm) 4” (100mm) 51 (1.44)
6SE6440-2UC22-2BA1 77 4” (100mm) 4” (100mm) 51 (1.44)
6SE6440-2UC23-0CA1 90 4” (100mm) 4” (100mm) 116 (3.28)
6SE6440-2UC24-0CA1 120 4” (100mm) 4” (100mm) 116 (3.28)
6SE6440-2UC25-5CA1 165 4” (100mm) 4” (100mm) 116 (3.28)
6SE6440-2UC27-5DA1 225 12” (300mm) 12” (300mm) 116 (3.28)
6SE6440-2UC31-1DA1 330 12” (300mm) 12” (300mm) 116 (3.28)
6SE6440-2UC31-5DA1 450 12” (300mm) 12” (300mm) 116 (3.28)
6SE6440-2UC31-8EA1 555 12” (300mm) 12” (300mm) 233 (6.60)
6SE6440-2UC32-2EA1 660 12” (300mm) 12” (300mm) 233 (6.60)
6SE6440-2UC33-0FA1 900 14” (350mm) 14” (350mm) 318 (9.00)
6SE6440-2UC33-7FA1 1100 14” (350mm) 14” (350mm) 318 (9.00)
6SE6440-2UC34-5FA1 1350 14” (350mm) 14” (350mm) 318 (9.00)
Figure 1-4 Heat Loss, Clearances & Air Flow (230V)
