Siemens A62 Service Manual

A70 Level 2 Service Manual
Copyright © Siemens Pte Ltd.
All Rights Reserved Mai 2005
COM D CCQ SLI APAC Page 3 of 36 Internal Use Only
1 Cellular Communication
1.1 Coverage Concept
The cellular system is made up of numerous transmitting and receiving sites, whose
individual coverage areas partially overlap. The concept of frequency re-use, same
frequency is used by several sites, allows a high traffic density in a wide area. Due to
the limited transmission range of the terminals, cellular systems are based on a large
number of base stations on the infrastructure side, scattered over the area to cover,
with each covering a fairly small geographical zone called cell. Cells are often
represented by hexagons (see figure 1.1.).
Figure 1.1 CELLULAR COVERAGE REPRESENTATION

Siemens A62 Specifications

General

Network	GSM 900 / 1800
Status	Discontinued
SIM	Mini-SIM
Type	Monochrome graphic
Alert types	Vibration; Downloadable polyphonic ringtones
Loudspeaker	No
3.5mm jack	No
Phonebook	500 entries
Call records	10 dialed, 10 received, 10 missed calls
Card slot	No
Internal	1.5 MB
EDGE	No
WLAN	No
Bluetooth	No
USB	No
Browser	WAP 2.0
Radio	No
Games	Yes
Java	Yes
Predictive text input	Yes
Organizer	Yes
Stand-by	Up to 300 h
Talk time	Up to 5 h
Weight	85 g
Ringtones	Polyphonic
GPRS	Class 8
Messaging	SMS, MMS
Battery	Li-Ion
