Company Confidential s Com
Copyright 2005© Siemens AG
Page 8 of 53
TD_Repair_L2.5_A70_A75_R1.0.pdf Release 1.0
4 Required Equipment for Level 2,5e
- GSM-Tester (CMU200 or 4400S incl. Options)
- PC-incl. Monitor, Keyboard and Mouse
- Bootadapter 2000/2002 (L36880-N9241-A200)
- Adapter cable for Bootadapter due to new Lumberg connector (F30032-P226-A1)
- Troubleshooting Frame A62/A65(A70/A75) (F30032-P405-A1)
- Power Supply
- Spectrum Analyser
- Active RF-Probe incl. Power Supply
- Oscilloscope incl. Probe
- RF-Connector (N<>SMA(f))
- Power Supply Cables
- Dongle (F30032-P28-A1) if USB-Dongle is used a special driver for NT is required
- Soldering and BGA Soldering equipment for lead free soldering.
Reference: Equipment recommendation
(downloadable from the technical support page)
5 Required Software for Level 2,5e
- Windows XP
- X-Focus
- GRT Version 2 or higher
- Internet unblocking solution (JPICS)
