The following detector models are analog types that must be
programmed for the air duct application using the control unit
configuration tool; that is, CSG-M, Zeus or FS-CT2, as appli-
cable.
To test the FP-11/-11C detector refer to its installation instruc-
tions. See Table A on page 12.
To test the HFP-11/HFPO-11/SFP-11/SFPO-11 detector refer
to its installation instructions. See Table A on page 12.
These tests ensure that the detector is within its listed and
marked sensitivity range. For additional instructions on
applying the Sensitivities mode, refer to the FireFinder-XLS
Manual, P/N 315-033744, the DPU Manual, P/N 315-033260 or
the SDPU Manual, P/N 315-033260C.
Functional Test Smoke Testing
Using TG-11 smoke test canister with testing nozzle model
AD-TGN (purchased separately) available from Siemens
Industry, Inc., insert the test gas nozzle into the hole in the
red plug in the unit cover. Press can against cover for about
1
/
2 second to release gas into the chamber.
DO NODO NO
DO NODO NO
DO NO
T SPRAT SPRA
T SPRAT SPRA
T SPRA
Y GAY GA
Y GAY GA
Y GA
S FOR MORE S FOR MORE
S FOR MORE S FOR MORE
S FOR MORE
THAN ½ SECONDTHAN ½ SECOND
THAN ½ SECONDTHAN ½ SECOND
THAN ½ SECOND
..
..
.
O O
O O
O
VER-VER-
VER-VER-
VER-
USE OF USE OF
USE OF USE OF
USE OF
TESTES
TESTES
TES
T GAT GA
T GAT GA
T GA
S MAS MA
S MAS MA
S MA
Y RESULY RESUL
Y RESULY RESUL
Y RESUL
T IN DETECTT IN DETECT
T IN DETECTT IN DETECT
T IN DETECT
OR CONOR CON
OR CONOR CON
OR CON
TT
TT
T
AMI-AMI-
AMI-AMI-
AMI-
NANA
NANA
NA
TION.TION.
TION.TION.
TION.
After 15 to 20 seconds the detector will go into alarm,
illuminating the detector LED and causing the duct unit
functions to operate; alarm relays will change state, and the
alarm related remote accessories, if attached, will function.
If no test gas is available to conduct functional testing,
remove cover and, while holding down the cover removal
switch, blow smoke from a smoldering cotton wick or punk
directly at the head to cause an alarm. The alarm indicator on
the detector should illuminate within one minute.
Refer to the following Installation Instructions for additional
information on testing each of these detectors:
