Private Communication Systems
Mobile Phones
6. Remove the card reader from the recess in the sreen
lid.
7. Then loosen the ringer plug-in connector on the radio
and control module and remove the ringer afterwards.
8. Unscrew the five cylinder-head screws in the screen lid
and remove the screen lid.
9. Remove the RF- and control modul.
10.Remove the battery contacts.
Service Manual C1x V 1.0 PN MP ST
R. Fleuren
Sm_C1x_lvl2_v10_w97.doc Page 7 of 23 09/98
