Technical data of CPU 31xC
6.4 CPU 313C-2 PtP and CPU 313C-2 DP
CPU 31xC and CPU 31x, Technical Data
6-18 Manual, 01/2006 Edition, A5E00105475-06
Technical data
CPU 313C-2 PtP CPU 313C-2 DP
Functionality
• MPI
Yes
• PROFIBUS DP
No
• Point-to-point connection
No
MPI
Services
• PG/OP communication
Yes
• Routing
No Yes
• Global data communication
Yes
• S7 basic communication
Yes
• S7 communication
– As server
– As client
•
• Yes
• No (but via CP and loadable FBs)
• Transmission rates
Max. 187.5 kbps
2nd interface
Type of interface Integrated RS422/RS485 interface Integrated RS485 interface
Physics RS 422/485 RS 485
electrically isolated Yes Yes
Interface power supply (15 to 30 VDC) No Max. 200 mA
Number of connections None 8
Functionality
• MPI
No No
• PROFIBUS DP
No Yes
• Point-to-point connection
Yes No
DP master
Number of connections – 8
Services
• PG/OP communication
– Yes
• Routing
– Yes
• Global data communication
– No
• S7 basic communication
– No
• S7 communication
– No
• Constant bus cycle time
– Yes
• SYNC/FREEZE
– Yes
• Enable/disable DP slaves
– Yes
• DPV1
– Yes
• Transmission rates
– Up to 12 Mbaud
• Number of DP slaves per station
– Max. 32
• Address area
– Max. 1 KB I / 1 KB O
• User data per DP slave
– Max. 244 bytes I / 244 bytes O
