System Function Blocks
144
S7-400 Instruction List
A5E00267845-01
Execution Time in s
SFC
No.
SFC Name Function
CPU
412
CPU
414
CPU
416
CPU
417
CPU
414-4H
417-4H
(solo)
CPU
414-4H
417-4H
(redun-
dant)
34 ALARM_8 Generate block-related message
without accompanying values for 8
signals JOB activated, SIG = 0–> 1
(1 - 420 bytes)
433 246 165 144 xx xx
JOB checked 206 118 78 68 xx xx
JOB finished, DONE = 1 213 121 80 70 xx xx
35 ALARM_8P Generate block-related message with
accompanying values for 8 signals
JOB activated, SIG = 0–> 1
(1 - 420 bytes)
549 -
582
306 -
326
209 -
222
182 -
190
xx - xx xx - xx
JOB checked 205 118 78 68 xx xx
JOB finished, DONE = 1 213 122 81 70 xx xx
36 NOTIFY Generate block-related message
without acknowledgment
JOB activated, SIG = 0–> 1
(1 - 420 bytes)
547 -
586
305 -
329
203 -
216
181 -
189
xx - xx xx - xx
JOB checked 204 117 78 67 xx xx
JOB finished, DONE = 1 213 121 81 70 xx xx
