Sublist of the System Status List (SSL)
152
S7-400 Instruction List
A5E00267845-01
Sublist of the System Status List (SSL), continued
SSL-ID Information Functions
Rack/Station Status Information
0092 Expected status of the central racks/stations of a DP master system
4092 Expected status of the stations of a DP master system which is connected via an external DP interface module
0192 Activation status of the stations of a DP master system which is connected via an external DP interface module
0292 Actual status of the central racks/stations of a DP master system
4292 Actual status of the stations of a DP master system which is connected via an external DP interface module
0392 Status of the back–up battery of a CPU rack if at least one battery fails
0492 Status of the entire back–up batteries of all racks of the a CPU
0592 Actual status of the racks in the central configuration/stations of DP master system which is connected via an external
DP interface module.
0692 OK status of the expansion units in the central configuration/stations of a DP master system which is connected via an
integrated DP interface module.
4692 OK status of the stations of a DP master system which is connected via an external DP interface module.
Addtional DP Master System Information
0195 Additional information on a DP master system
0F95 Only partial list header information
