Siemens CPU 414-3 User Manual

Load Instructions
50
S7-400 Instruction List
A5E00267845-01
Load Instructions, continued
In-
Length
Execution Time in s
In-
struc-
Address
Description
Length
in
Execution Time in

s
struc-
tion
Address
ID
Description
in
Words
CPU 412 CPU 414 CPU 416 CPU 417
L
k8
k16
k32
Load ...
8-bit constant into ACCU1-LL
16-bit constant into ACCU1-L
32-bit constant into ACCU1
2
2
3
0.125
0.125
0.185
0.075
0.075
0.112
0.05
0.05
0.075
0.042
0.042
0.062
Parameter Load constant into ACCU1
(addressed via parameter)
2 0.3+ 0.18+ 0.12+ 0.12+
L 2#n Load 16-bit binary constant into
ACCU1-L
2 0.125 0.075 0.05 0.042
Load 32-bit binary constant into
ACCU1
3 0.185 0.112 0.075 0.062
B#16#p Load 8-bit-hexadecimal constant
into ACCU1-L
1 0.1 0.06 0.04 0.03
L W#16#p Load 16-bit hexadecimal
constant into ACCU1-L
2 0.125 0.075 0.05 0.042
DW#16#p Load 32-bit hexadecimal
constant into ACCU1
3 0.185 0.112 0.075 0.065
