Siemens RDF301, RDF301.50..., RDF600KN, RDF600KN/VB, RDF600KN/S Basic Documentation CE1P3171en
Smart Infrastructure 2020-02-21
Operational data Switching differential (adjustable)
Heating mode (P30)
Cooling mode (P31)
2 K (0.5...6 K)
1 K (0.5...6 K)
Setpoint setting and range
Comfort (P08)
Economy (P11-P12)
Protection (P65-P66)
21°C (5...40 °C)
15°C/30 °C (OFF, 5...40 °C)
8°C/OFF (OFF, 5...40 °C)
Multifunctional input X1/X2
Input X1 default value (P38)
Input X2 default value (P40)
Selectable 0...8
3 (operating mode
switchover)
1 (external temperature
sensor)
Built-in room temperature sensor
Measuring range
Accuracy at 25 °C
Temperature calibration range
0…49 °C
< ± 0.5 K
± 3.0 K
Settings and display resolution
Setpoints
Current temperature value displayed
0.5 °C
0.5 °C
Environmental conditions Operation
Climatic conditions
Temperature
Humidity
IEC 60721-3-3
Class 3K5
0...50 °C
<95% r.h.
Transport
Climatic conditions
Temperature
Humidity
Mechanical conditions
IEC 60721-3-2
Class 2K3
-25...60 °C
<95% r.h.
Class 2M2
Storage
Climatic conditions
Temperature
Humidity
IEC 60721-3-1
Class 1K3
-25...60 °C
<95% r.h.
Standards and directives
EU Conformity (CE) RDF301...
RDF600KN...
Electronic control type
CE1T3171xx
*)
CE1T3171xx_1
*)
2.B (micro-disconnection
on operation)
RCM Mark conformity (Emission) RDF301…
RDF600KN…
CE1T3171en_C1
*)
CE1T3076en_C1
*)
Safety class II as per EN60730
Pollution class Normal
Degree of protection of housing IP30 as per EN60529
Housing flammability class according to UL94 V-0
The product environmental declaration CE1E3076_3en
*)
(for RDF600KN,
RDF600KN/VB and RDF600KN/S) contains data on environmentally compatible
product design and assessments (RoHS compliance, materials composition,
packaging, environmental benefit, disposal).
General Connection terminals Solid wires or prepared
stranded wires
1 x 0.4…1.5 mm
2
Minimal wiring cross section on
L, N, Q1, Q2, Q3, Y11, Y21
min 1.5 mm
2
Housing front color RAL 9003 white
RAL 9004 black
Weight without / with packaging RDF301...
RDF600KN…
0.240 kg / 0.320 kg
0.150 kg / 0.220 kg
*)
The documents can be downloaded from http://siemens.com/bt/download.
Environmental
Compatibility
