Siemens DO0570C User Manual

9
en
Checking the heating
■ Turn the rotary selector switch to “III” (approx. 85 °C).
■ Monitor the heating process until the pilot lamp switches
off after approx. 12 ‒ 18 minutes.
■ Check the temperature.
■ Caution: If the safety temperature limitation has switched
off the small water heater, unplug the mains plug, open
the warm water tap and allow approx. 4 litres of water to
flow. Then plug the mains plug back in.
The appliance is ready again for operation.
Limitation of the water temperature
The temperature of the water leaving the tap for the small
water heater can be mechanically set to stage “I” (approx.
38 °C) or stage “e” (approx. 60 °C) (see “Operation”, page 9).
Conserving energy
■ Set the rotary selector to “e” to conserve energy.
■ Hand over the installation and operating instructions to
the user and explain how the appliance operates.
Technical data
Type DO0570C
Rated output [kW] 2.2
Rated capacity [l] 5.0
CLICKFIX plus installation
technology ✓
Mixed water quantities 40 °C
(15 °C/85 °C) / (15 °C/85 °C) [l] 9.5/14
Variable temperature
adjustment up to [°C] 85
Stand-by power consump-
tion at 65 °C/24 h [kWh/d] 0.20
Electrical connection [V] 230
Heat-up time to 60 °C
(supply temperature 12 °C) [min] 8
Fuse protection [A] 10
Water connection ["] 3/8
Maximum flow [l/min] 5
Cable length [m] 0.6
Dimensions
(Height x Width x Depth) [mm] 435 x 270 x 240
Weight, filled [kg] 7.8
Energy efficiency class
A
Load profile
XXS
Annual energy consumption
[kWh] 484
Daily energy consumption
[kWh] 2.340
Sound power level
[dB] 15
Hot water heating energy
efficiency [%] 36.8
Operating instructions
■ Before using the appliance, please read the instruc-
tions carefully and observe them!
■ Important: The appliance may never be exposed to frost!
Risk of electric shock!
If a fault occurs, immediately disconnect the plug
from the power supply!
Immediately shut off the cold water supply to the
appliance should it leak.
Please read and observe the detailed safety instructions
at the start of these instructions!
IV.
Operation
The small water heater heats and stores drinking water up to
approx. 85 °C.
Setting the water temperature
■ The required outlet temperature from 35 °C to 85 °C can
be set with the rotary selector switch.
or:
■ Set the required fixed outlet temperature (A):
❄ Frost protection
I Approx. 38 °C (soft lock-in)
e Conserve energy approx. 60 °C (soft lock-in)
III Hot water approx. 85 °C
The pilot lamp lights up during heat up; a little expansion
water drips from the outlet.
The appliance with be covered more quickly with limescale
at higher temperatures.
Tip: Set the rotary selector switch to “e” to operate the appli-
ance economically and to reduce the effects of limescale.
Note: If the appliance has not been used for an extended
period, e. g. during a holiday, allow the water to briefly heat
up to stage “III”.
Limitation of the water temperature
Limit the outlet temperature to avoid scalding with hot
water:
■ Set the rotary selector switch to “●“.
■ Open the cover of the rotary selector switch.
■ Select between “I” = approx. 38 °C (B1) or “e” = approx.
60 °C (B2).
■ Close the cover.
Switching off
■ Set the rotary selector switch to “●“ (A). The heating is
switched off.
Cleaning
Do not use aggressive or abrasive cleaning detergents!
Do not use a steam cleaner.
■ Clean appliance externally with a mild cleaning agent.
■ Clean the dirt and lime scale deposits in the aerator filter.
