Information and Communication
Communication Devices
a multimeter. The fuse is defective if the resistance higher than 10
ohms
4.4.1.2Repair by component change
Use soldering iron to remove defective fuse.
Avoid excessive heat!
Watch surrounding components!
Resolder new fuse afterwards.
4.4.1.3Repair by SW-Booting
Not possible!
4.4.1.4Test
Retest handset after repair as described above.
The resistance must now be close to zero.
4.4.2List of needed material
4.4.2.1Components
Fuse
Part-Number: L36145-A820-Y10
4.4.2.2Jigs and Tools
Soldering Iron
4.4.2.3Special Tools
Multimeter
4.4.2.4Working materials
Desolder Wick / Braid
Solder
4.4.3Drawings
V1.2 Page 14 of 22 ICP CD ST
D. Schnoor
06/98
