8 K42
GB
Relay terminal blocks
6
For locks with failsafe (power to lock) function,
connect lock to terminal 5, not 3.
Technical data
Power voltage: 12-24 V AC/DC.
Power consumption: 8 mA quiescent.
Relay output: Voltage free relay, max. 1A,
28V DC
Temperature Range: -35° to +55°C.
Environment: Indoor – or outdoor use
(IP54 design).
Dimension: 140 x 80 x 40 mm (hxwxd).
Recommended mounting height 1 200 – 1 400 mm.
If the code lock is to be flush mounted, the flush
mounting unit BB3 should be used.
