en Installation instructions
16
6.
Screw on the angle bracket.
Installing the appliance
WARNING‒Risk of injury!
Components inside the appliance may have sharp
edges.
▶ Wear protective gloves.
1.
Remove the protective film from the rear.
‒ Once the appliance is installed, fully remove the
protective film.
2.
Slide the retainers into the rear of the appliance
and screw them in tightly .
3.
Hook on the appliance.
4.
Align the appliance horizontally using threaded pins.
5.
Secure the appliance to the unit.
6.
Secure the cover to the bottom of the appliance.
7.
Secure the appliance to the wall.
