Technical data (continued)
LFS1.2 terminal 7
voltage output for flame
supervision with
ionization probe
10
7782d01en/0216
9
8
DC
7
6
Volts
5
4
3
2
1
0
0
10
20
30
Detector current µA
Parameter 699.00 = 5
Parameter 699.00 = 13 *)
Parameter 699.00 = 35
*) Factory setting
LFS1.2 terminal 7
voltage output for flame
supervision with QRA2 /
QRA2M / QRA4 /
QRA4M / QRA10 /
QRA10M
10
7782d02en/0416
9
8
DC
7
6
Volts
5
4
3
2
1
0
0
20
40
60
80
100
Parameter 699.01 = 5
Parameter 699.01 = 16 *)
Parameter 699.01 = 35
Detector current µA
*) Factory setting
LFS1.1 terminal 7
voltage output for flame
supervision with RAR9
10
9
8
7
6
DC
5
4
Volts
3
2
1
0
0
20
40
60
Detector current µA
Parameter 699.01 = 5
Parameter 699.01 = 16 *)
Parameter 699.01 = 35
*) Factory setting
The information applies under the following conditions:
- Mains voltage 230 V AC / 50 Hz or 120 V AC / 60 Hz, depending on type
- Ambient temperature 23 °
22/40
Building Technologies CC1N7782en 18.04.2018
