Disassembly and Disposal Instructions 3
Siemens AG SPL1-130.163.01 Page 3 of 4 MODULARIS Uro Plus
Medical Engineering Rev. 02 09.99 TD PS 24
General 1
The disposal of hazardous materials (materials that may be harmful to the environment) in
a responsible manner is as important when disposing of the system/equipment as it is
when replacing components and assemblies while the system is in use.
Disposal list 1
The following list shows the components/assemblies of the MODULARIS and the hazard-
ous materials which they contain.
The corresponding assemblies/parts are to be disposed of by an authorized waste dis-
posal company.
Component/Assembly Location Hazard/Hazardous material Qty
ESWT cooling system 1/Fig. 1 Coolant R 134 A 0.1 kg
Board D3 4/Fig. 2 Lithium 1
Capacitor 2/Fig. 1 Oil 0.2 L
Spark gap 3/Fig. 1 Implosion 1
Support 5/Fig. 1 carbon fiber laminate ca. 6 kg
(without mechanics)
Ultrasoundapplicator
holder
6/Fig. 3 Oil 0.1 L
