Siemens P2 - Page 23

21
Table P2-8 – Branch Circuit Breakers
Max. Bolt-On No.
Maximum Interrupting Rating (kA)
Amp Breaker of Amp
Volts – AC DC
Rating Type Poles Rating 120 120/240 240 277 480 600 250
1 15 - 70 10 — — — — — —
BL 2 15 - 100 — 10 — — — — —
3 15 - 100 — — 10 — — — —
BL, HID
1 15 - 30 10 — — — — — —
2 15 - 30 — 10 — — — — —
2 15 - 100 — — 10 — — — —
BLE
1 15 - 30 10 — — — — — —
2 15 - 60 — 10 — — — — —
BLEH
1 15 - 30 22 — — — — — —
2 15 - 60 — 22
BLF
1 15 - 30 10 — — — — — —
2 15 - 60 — 10 — — — — —
100
BLHF
1 15 - 30 22 — — — — — —
3 15 - 60 — 22 — — — — —
2 15 - 30 10 — — — — — —
3 15 - 30 — 10 — — — — —
BAF 1 15, 20 10 — — — — — —
BAFH 1 15, 20 22 — — — — — —
1 15 - 70 — 22 — — — — —
BLH 2 15 - 100 — 22 — — — — —
3 15 - 100 — — 22 — — — —
1 15 - 70 — 65 — — — — —
HBL 2 15 - 100 — 65 — — — — —
3 15 - 100 — — 65 — — — —
1 — 65 — 14 — — 14
BQD6 2 15 - 100 — 65 — — 10 10 14
3 — — 65 — 10 10 14
ED2 1 15 - 100 10 — — — — — —
2/3 — 10 — — — — 5 (2-P)
ED4
1 15 - 125 65 — — 22 — — —
2 — — 65 — 18 — 30
3 — — 65 — 18 — —
ED6 2 15 - 125 — — 65 — 25 18 30
125
3 — — 65 — 25 18 —
1 — — — — — — —
*CED6 2 15 - 125 — 200 200 200 200 100 —
3 — 200 200 200 200 100 50
QJ2 2/3 60 - 225 — — 10 — — — —
225
QJH2 2/3 60 - 225 — — 22 — — — —
QJ2-H 2/3 60 - 225 — — 42 — — — —
HQJ2H 2/3 100 - 225 — — 100 — — — —
NOTE: QJ Breakers are single mounted in unit space and take 6” of unit space.
Limited to (3) per panel max. BL, HBL, BLH and BQD6 breakers are mounted in
common mountings in 3” or (6) pole increments. ED2, ED4, ED6 and HED4 breakers
are mounted in common mountings in 3” or (6) pole increments.
Table P2-9 – Branch Neutral Connections
Wire Range Max. Number of Connections Max. Amps
Q
#14-#6 26 65
#14-1/0 28 125
#6 - 350 Kcmil 3 250
(1) #4-600 Kcmil
1 400
or (2) #6-250 Kcmil

QQQQQQ
Based on 75 degree copper.
*Contact local Siemens representative before ordering.
Application
