Catalogue Numbering System
Reference Guide
P1
C

FX
250
A
T
S
Type of Panel
P1, P2, S5, F2
Voltage and System*
"71IBTF8JSF
$:71IBTF8JSF
%71IBTF8JSF
&:71IBTF8JSF
-:71IBTF8JSF
/7%$XJUI1PMF#SBODI%FWJDFT
07%$XJUI1PMF#SBODI%FWJDFT
17%$
Circuits or Enclosure Height
1DDU
1DDU
4'wwwIU
Main Lug (ML)
Amperage
1
1
4'
Bus Material
A = Tin Plated Aluminum Temp Rated (Standard)
C = Tin Plated Copper Temp Rated (Optional)
E = Silver Flashed Cu (Optional)
Feed Location
T = Top
B = Bottom
Mounting
S = Surface
F = Flush
Main Breaker
See Main Breaker Table coding below,
* Other voltages available. Please contact your local Siemens representative.
Main Breaker Coding
(Breaker Type) Code
(BL) BL, (BLH) LH, (HBL) HL, (BQD6) BD, (ED4) E4, (ED6) E6, (HED4) H4, (HED6) H6, (QJ2) QJ, (QJH2) QH, (QJ2-H) Q2, (FXD6) FX,
(HFD6) HF, (JD6) J6, (JXD6) JX, (HJD6) HJ, (CJD6) CJ, (SJD6) SJ, (LXD6) LX, (LD6) L6, (HLD6) HL, (MD6) M6, (HMD6) HM, (CMD6)
CM, (SMD6) SM, (ND6) N6, (HND6) HN, (CND6) CN, (SND6) SN
