Siemens raa20 series User Manual

4/4
Siemens Room Thermostat RAA20 CE1N3002en
Building Technologies 25.02.2008
EMC – standard
Emission
EN 61000-3-2 and
EN 61000-3-3
C-Tick conformity to
EMC emission standard
AS/NSZ 4251.1:1994
Safety standard
Degree of protection of housing
II to EN 60730
IP30 to EN 60529
Screw terminals for
2 x 1.5 mm
2
or 1 x 2.5 mm
2
(min. 0.5 mm
2
)
Weight 0.14 kg (RAA20)
0.20 kg (RAA200)
Color White, NCS S 0502-G (RAL 9003)
Connection diagrams
N
L
D1
N1
Y1 Y2
L
T
3001A01
N
L
N1
Y1 Y2
L
D2
T
3001A02
D1 Zone valve or thermal
valve for heating
D2 Zone valve or thermal
valve for cooling
L Switching voltage
AC 24…250 V
N1 Room thermostat
Y1 Control output "Heat-
ing", AC 24…250 V
Y2 Control output "Cool-
ing", AC 24…250 V
N Neutral conductor
T Thermostat element
(gas-filled diaphragm)
Dimensions
96,4
99,6
42,8
3002M01
3001M02
30 30
28
3,6
28
86
86
2828 30
30
Room thermostat /
baseplate
RAA20
RAA200
©2003 – 2008 Siemens Switzerland Ltd. Subject to change
