RAB20 Series Two-pipe Fan Coil Room Thermostat Technical Instructions
Document Number 155-526P25
March 2, 2007
Information in this publication is based on current specifications. The company reserves the right to make changes in specifications and models as
design improvements are introduced. Other product or company names mentioned herein may be the trademarks of their respective owners.
© 2007 Siemens Building Technologies, Inc.
Siemens Building Technologies, Inc.
1000 Deerfield Parkway
Buffalo Grove, IL 60089-4513
U.S.A.
Your feedback is important to us. If you have
comments about this document, please send them to
SBT_technical.editor.us.sbt@siemens.com
Dimensions
Dimensions in inches
(millimeters)
3.80
(96.4)
4.45
(113.1)
1.68
(42.8)
TH0495R2
Figure 7. RAB20… Unit.
1.18
(30)
0.66
(16.9)
2.56 (65)
1.97 (50)
0.51 (13)
2.56
(65)
0.51
(13)
1.18
(30)
1.38
(35)
0.46
(11.8)
1.00
(25.5)
3.9
(99)
3.38
(86)
Ø 0.14 (3.6)
Ø 0.25 (6.4)
TH0496R2
Figure 8. Base Plate.
0.91(23) 0.91(23)
0.91(23)0.91(23)
1.64(41.75)1.64(41.75)
4.72(120)
4.72(120)
TH0512R1
3.29(83.5)
0.33(8.5)
1.1(28)1.1(28)
1.17(29.6) 1.1(28)
1.18(30)1.18(30)
0.04(1)
1.1(28)1.1(28)
4.21(107)
4.21(107)
TH0513R1
Figure 9. ARG70.
Document No. 155-526P25
Country of Origin: US
Page 9
