Siemens Room Temperature Controllers N3057en
Building Technologies 2014-10-28
Para-
meter
Meaning Setting range Factory
setting
P01
Setpoint of heating in Economy (Energy saving) mode
(Wheat
Eco
)
OFF, 5 °C…Wcool
Eco
16 °C
1)
P02
Setpoint of cooling in Economy (Energy saving) mode
(Wcool
Eco
)
OFF, Wheat
Eco
…40 °C
28 °C
1)
P03
Setpoint of heating in Protection (Standby) (Wheat
Stb
)
OFF, 5 °C…Wcool
Stb
OFF
P04
Setpoint of cooling in Protection (Standby) (Wcool
Stb
)
OFF, Wheat
Stb
…40 °C
OFF
P05
Minimum setpoint limitation in Normal operation (Wmin
Comf
)
5 °C…Wmax
Comf
5 °C
P06
Maximum setpoint limitation in Normal operation (Wmax
Comf
)
Wmin
Comf
…40 °C
35 °C
P07
Sensor calibration
-3…+3 K
0 K
P08
Switching differential heating mode SDH
0.5…+4K
2 K
P09
Switching differential cooling mode SDC
0.5…+4K
1 K
P10
Switching differential fan speed 2 in heating mode SDH2
0.5…+4K
1 K
P11
Switching differential fan speed 2 in cooling mode SDC2
0.5…+4K
1 K
P12
Switching differential fan speed 3 in heating mode SDH3
0.5…+4K
1 K
P13
Switching differential fan speed 3 in cooling mode SDC3
0.5…+4K
1 K
P14
Dwelling time of auto fan speeds
1…5 minutes
2 min
P15
Minimum output on time (Y11)
1…10 minutes
1 min
P16
Minimum output off time (Y11)
1…10 minutes
1 min
P17
Selection of °C or °F
°C or °F
°C
P18
Display of temperature or setpoint
OFF: Setpoint
ON: Room (or return air)
temperature
ON
P19 Operating action of remote changeover input
0: Normally open (N.O)
1: Normally closed (N.C.)
0
1)
P20
Fan control in
Economy (Energy saving) mode
OFF in dead zone
ON in dead zone
OFF
1)
P21 Fan control in Normal operation
OFF in dead zone
ON in dead zone
OFF
P22 Heating / cooling mode
0: Heating only
1: Cooling only
2: Automatic H/C
changeover
1: Cooling
only
1)
P23
Heating / cooling changeover switching point cooling
10…25 °C
16 °C
1)
P24
Heating / cooling changeover switching point heating
27…40 °C
28 °C
1)
P25 Infrared receiver (only with RDF.../IR)
0: Disabled
1: Enabled
1
P98 Active temperature sensor
0: Internal sensor
1: External sensor
Diagnostic
value
1)
P99
Value of current heating / cooling changeover temperature
reading and indication of current mode
100 = input open  mode
0…49 °C = cur. temp. value
00 = input bridged 
mode
OFF= not commissioned as
automatic H/C changeover
Diagnostic
value
1)
1) Not available with RDF110.2
Type summary
Type
Features
RDF110
With input for automatic heating / cooling changeover or return air
temperature sensor
With input for operating mode changeover
RDF110.2
With manual heating / cooling changeover
Without input for sensor
Without input for operating mode changeover
RDF110/IR
*)
Same as RDF110 plus infrared remote control
RDF110.2/IR
*)
Same as RDF110.2 plus infrared remote control
*) Type is not orderable any more
Control parameters of the RDF110 and RDF110.2
