Siemens RDF301, RDF301.50..., RDF600KN, RDF600KN/VB, RDF600KN/S CE1N3171en
Smart Infrastructure Semi flush-mount communicating room thermostats 2020-02-21
Electrical actuator, 3-position
(for radiator valve)
SSA31... 4893
Electrical actuator, 3-position
(for 2- and 3-port valves / V…P45)
SSC31 4895
Electrical actuator, 3-position
(for small valve 2.5 mm)
SSP31… 4864
Electrical actuator, 3-position
(for small valve 5.5 mm)
SSB31... 4891
Electrical actuator, 3-position SAS31… 4581
*) The documents can be downloaded from http://siemens.com/bt/download.
For the maximal number of actuators in parallel, refer to information in the data sheets
of the selected actuators and to this list, depending on which value is lower:
· Parallel operation of max 6 SS… actuators (3-pos) is possible.
· Parallel operation of max 10 on/off actuators is possible.
Accessories
Designation Product no. / SSN
Data
s
heet
Changeover mounting kit
(50 pcs/package)
ARG86.3 N3009
Plastic mounting bracket for semi-
flush-mount thermostats for increasing
the headroom in the conduit box by
10mm
ARG70.3 N3009
Conduit box for semi-flush mounted
thermostat RDF301...
ARG71 /
S55770-T137
N3009
KNX Power supply 160 mA (Siemens BT LV)
5WG1 125
-
1AB02
--
KNX Power supply 320 mA (Siemens BT LV)
5W
G1
125
-
1AB12
--
KNX Power supply 640 mA (Siemens BT LV)
5WG1 125-1AB22
--
3-position actuators
Note:
