Siemens RDF301

Applications for Universal systems
Application and output signal, DIP switches, diagram
• Chilled / heated ceiling ON/OFF
(heating or cooling)
1
ON
2 3
• Chilled / heated ceiling with electric
heater (heating or cooling) ON/OFF
1
ON
2 3
3191S11
N1
T
B1
T
B2
T
D3
Y1
3191S12
N1
T
YE
B1
T
B2
T
D3
Y1
• Chilled / heated ceiling 3-position
(heating or cooling)
1
ON
2 3
• Chilled ceiling and radiator ON/OFF
(heating and cooling)
1
ON
2 3
3191S11
N1
T
B1
T
B2
T
D3
Y1
3191S13
N1
T
B1
T
D3
Y1
YR
5 / 17
Siemens RDF301, RDF301.50..., RDF600KN CE1N3171en
Building Technologies Semi flush-mount communicating room thermostats 2014-05-23
