Siemens RDF301, RDF301.50..., RDF600KN, RDF600KN/VB, RDF600KN/S CE1N3171en
Smart Infrastructure Semi flush-mount communicating room thermostats 2020-02-21
· AC 230 V operating voltage
· User and parameter settings can be retained or restored with power loss
Additional RDF600KN, RDF600KN/VB features:
· Independent function for window contact, presence detector (standard
presence and hotel presence)
Additional RDF600KN/S features:
· Independent function for window contact, presence detector (standard
presence and hotel presence)
· Four buttons to control KNX actuators via KNX S-mode
(functions: switching, dimming, blinds control, 8-bit scene)
Additional RDF301.50 features:
· Four buttons to control KNX actuators via KNX S-mode
(functions: switching, dimming, blinds control, 8-bit scene)
Additional RDF301.50H features:
· Four buttons for hotel functions MUR (Make Up Room), DND (Do Not
Disturb) via KNX S-mode
Type of mounting / suitable conduit boxes:
· RDF600KN… for round box, with min 60 mm diameter, min 40 mm depth
and recessed square box with 60.3 mm fixed centers
· RDF301... for recessed square box with 60.3 mm fixed centers
Use
Room temperature control (heating or cooling) in individual rooms and zones by
means of:
· 2-pipe fan coil units
· 2-pipe fan coil units with electric heater
· 4-pipe fan coil units
· Compressors in DX-type equipment
· Compressors in DX-type equipment with electric heater
The RDF301... / RDF600KN… controls:
· One 1-speed or 3-speed fan
· One or two on/off valve actuators
· One on/off valve actuator and one 1-stage electric heater
· One 3-position valve actuator
· One 1-stage compressor in DX-type equipment, or one 1-stage compressor with
electric heater
Used in systems with:
· Heating or cooling mode
· Automatic heating/cooling changeover
· Manual heating/cooling changeover
· Heating and cooling mode (e.g. 4-pipe system)
The room thermostats are delivered with a fixed set of applications.
The relevant application is selected and activated during commissioning using one
of the following tools:
· Synco ACS
· ETS
· Local DIP switch and HMI
