Siemens RDF30U Installation Instructions

Document No. 129-497
Installation Instructions
May 18, 2011
Information in this publication is based on current specifications. The company reserves the right to make changes in specifications and models as design improvements are introduced. Teflon is a registered
trademark of DuPont. Product or company names mentioned herein may be the trademarks of their respective owners. © 2011 Siemens Industry, Inc.
Siemens Industry, Inc.
Building Technologies Division
1000 Deerfield Parkway
Buffalo Grove, IL 60089
+ 1 847-215-1000
Your feedback is important to us. If you have comments about this document,
please send them to SBT_technical.editor.us.stb@siemens.com
Commissioning (by qualified HVAC Installer)
Para-
meter
Controller’s parameter factory settings: Default settings
Setting range (all settings can be made in increments of 0.5°K)
RDF10U RDF20U RDF30U RDF50.1U RDF60.1U
P01
Setpoint of heating in night setback (Economy) mode
(operating mode changeover switch activated)
61°F (16°C)
OFF, 41°F to 68°F (5°C to 20°C)
P02
Setpoint of cooling in night setback (Economy) mode
(operating mode changeover switch activated)
82°F (28°C)
OFF, 70°F to 95°F (21°C to 35°C)
P03
Setpoint of heating in Freeze Protection (standby) position
46°F (8°C) OFF, 41°F to 68°F (5°C to 20°C)
P04
Setpoint of cooling in standby position
OFF
OFF, 70°F to 95°F (21°C to 35°C)
P05
Minimum (lower) setpoint limit stop in normal mode
41°F (5°C)
41°F to Wmax
Norm
(5°C to
Wmax
Norm
)
P06
Maximum (upper)setpoint limit stop in normal mode
95°F (35°C)
Wmin
Norm
to 95°F (Wmin
Norm
to
35°C)
Legend to table
P07
Heat/cool changeover switching point cooling
61°F (16°C) 50°F to 77°F (10°C to 25°C)
X
P08
Heat/cool changeover switching point heating
82°F (28°C) 81°F to 104°F (27°C to 40°C)
Adjustable: please record
all changes you make
X
P09
Sensor calibration 0 (0 K)
-3 K to +3 K (-5.5°F to 5.5°F)
Not adjustable/display only
P10 Switching differential in heating mode *
2 K (3.6°F) 1°F to 7°F (0.5 K to 4 K)
x Not adjustable/no display
P11 Switching differential in cooling mode *
1 K (1.8°F) 1°F to 7°F (0.5 K to 4 K)
Integration time 5 minutes 1 to 10 minutes
X X X
P12
Dead zone in normal operation *
2 K (3.6°F) 1°F to 18°F (0.5 K to 10 K)
X X X
P13
Active temperature sensor (no setting, display only)
-
1: room temperature sensor active
2: return air temperature sensor active
P14
Value of current room temperature reading (no setting, display only)
-
32°F to 120°F (0°C to 49°C) = current temperature value
P15
Value of current heat-cool changeover temperature reading including indication of
current mode ( , ) (no setting, display only)
-
100 = input open (no sensor connected, heating mode [ ]) 32°F
to 120°F (0°C to 49°C) = current temp. value
00 = input bridged, cooling mode ( )
X
P16
Purging function 0 minutes
0 minutes: not active
1 to 5 minutes active with selected duration
X
P17
Fan control in energy saving mode
OFF: fan is off in the dead zone. ON: fan is on in the dead zone.
OFF
ON: running in selected speed or in speed one if in
standby position
Setpoint differential *
2 K (3.6°F) 1°F to 9°F (0.5 K to 5 K)
X X X
P18
Test mode for checking the actuator direction (note that this parameter can be quit
only if the setting is back at “---” and by pressing buttons + and – simultaneously)
---
“---“ = no signal on outputs Y1 and Y2
OPE = output Y1 forced open
CLO = output Y2 forced closing
X X X X
P19
Minimum out
p
ut on-time 1 minute 1 to 20 minutes
(
in increments of 1 minute
)
X X
P20
Minimum output off-time 1 minute 1 to 20 minutes (in increments of 1 minute)
X X
P21
Fan overrun see list 0 to 300 seconds (in increments of 10 seconds)
X (60s) (0 s) X X
P22
Point of reference for setpoint in Normal mode HA HA: heating sequence
CL: cooling sequence
X X X
P23
Display unit of measurement
°F °F
°C
* Note: This parameter is in degrees Kelvin, 1°K = 1.8°F).
Document No. 129-497
Printed in the USA
Page 7 of 7
