Chapter 4
Communication Ports
RUGGEDCOM RST2228
Installation Guide
26 SFP Transceivers
NOTE
When more than two 40km or 80km SFP+ tranceivers are installed, the maximum temperature at
which the device can operate will be reduced to 75 °C (165°F).
LEDs
Each socket features an LED that indicates its link state.
State Description
Green (Solid) Link established
Green (Blinking) Activity
Off No link detected
Compatible SFP Transceivers
The following SFP transceivers are compatible with the RUGGEDCOM RST2228. For more information, including
installation/removal instructions and ordering information, refer to the RUGGEDCOM SFP Transceiver Catalog
[https://support.industry.siemens.com/cs/ca/en/view/109482309].
IMPORTANT!
Only use SFP transceivers approved by Siemens for RUGGEDCOM products. Siemens accepts no liability
as a result of performance issues related in whole or in part to third-party components.
SFP Transceiver Order Code
Speed
(Mbit/s)
Mode
a
Nominal Distance (km)
RUGGEDCOM SFP1112-1 6GK6000-8CG01-0AA0 10/100/1000 — 0.1
RUGGEDCOM SFP1121-1FX2A
b
6GK6000-8FE50-0AA0 100 MM 2
RUGGEDCOM SFP1121-1FX2
c
6GK6000-8FE51-0AA0 100 MM 2
RUGGEDCOM SFP1131-1FX20
c
6GK6000-8FE52-0AA0 100 SM 20
RUGGEDCOM SFP1131-1FX50
c
6GK6000-8FE53-0AA0 100 SM 50
RUGGEDCOM SFP1131-1FX90
c
6GK6000-8FE54-0AA0 100 SM 90
RUGGEDCOM SFP1122-1SX 6GK6000-8FG51-0AA0 1000 MM 0.5
RUGGEDCOM SFP1122-1SX2 6GK6000-8FE58-0AA0 1000 MM 2
RUGGEDCOM SFP1132-1LX10 6GK6000-8FG52-0AA0 1000 SM 10
RUGGEDCOM SFP1132-1LX25 6GK6000-8FG53-0AA0 1000 SM 25
RUGGEDCOM SFP1132-1LX40 6GK6000-8FG57-0AA0 1000 SM 40
RUGGEDCOM SFP1132-1LX70 6GK6000-8FG54-0AA0 1000 SM 70
RUGGEDCOM SFP1132-1LX100 6GK6000-8FG55-0AA0 1000 SM 100
RUGGEDCOM SFP1132-1LX115 6GK6000-8FE56-0AA0 1000 SM 115
RUGGEDCOM SFP2133-1LR10
b
6GK6000-8FT51-0AA0 10000 SM 10
RUGGEDCOM SFP2133-1ER40
b
6GK6000-8FT53-0AA0 10000 SM 40
