Siemens SAS61.33U

Document No: 129-612
Installation Instructions
January 19, 2016
Information in this publication is based on current specifications. The company reserves the right to make changes in specifications and
models as design improvements are introduced. Product or company names mentioned herein may be the trademarks of their respective
owners. © 2016 Siemens Industry, Inc.
Siemens Industry, Inc.
Building Technologies Division
1000 Deerfield Parkway
Buffalo Grove, IL 60089-4513
USA
Tel. +1 847-215-1000
Your feedback is important to us. If you have comments
about this document, please send them to
sbt_technical.editor.us.sbt@siemens.com
Document No. 129-612
Printed in the USA
Page 3 of 3
Dimensions
A
B
C1
C2
D
E
►
►►
Inches
5.9
3.1
0.9
2.8
1.2
0.9
4
8
mm
151
80
21.9
71.1
29.9
21.8
100
200
Figure 4. SAS61.03U Actuator Dimensions.
A
B
C1
C2
D
E
►
►►
Inches
5.9
3.1
0.9
3.3
1.2
0.9
4
8
mm
151
80
21.9
84.6
29.9
21.8
100
200
Figure 5. SAS61.33U Actuator Dimensions.
