Page #97 background imageLoading...
Page #97 background image
Technical Specifications
7.1 Technical specifications
SCALANCE X-200
Compact Operating Instructions, 12/2010, A5E00813159-11
97
Device type
SCALANCE
Attachment of end devices
or network components
over twisted pair
Attachment of end devices
or network segments over
fiber-optic cable
Connector for power
supply
Connector for
signaling contact
X202-2P IRT PRO 2 x RJ-45 jacks with
MDI-X pinning 10/100
Mbps (half / full duplex)
2 SC RJ jacks (push-pull)
(100 Mbps, full duplex to
100BaseFX)
2 x 5-pin Power Plug Pro
connectors (male)
1 x 5-pin b-coded M12
connector (male)
X201-3P IRT PRO 1 x RJ-45 jack with MDI-X
pinning 10/100 Mbps (half
/ full duplex)
3 SC RJ jacks (push-pull)
(100 Mbps, full duplex to
100BaseFX)
2 x 5-pin Power Plug Pro
connectors (male)
1 x 5-pin b-coded M12
connector (male)
X202-2P IRT 2 x RJ-45 jacks with
MDI-X pinning 10/100
Mbps (half / full duplex)
2 SC RJ jacks (push-pull)
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X201-3P IRT 1 x RJ-45 jack with MDI-X
pinning 10/100 Mbps (half
/ full duplex)
3 SC RJ jacks (push-pull)
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X200-4P IRT - 4 SC RJ sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
Table 7- 3 Electrical data
Device type
SCALANCE
Power supply
2 x 24 VDC
(18-32 V DC)
SELV (Safety Extra
Low Voltage)
Power loss at 24 VDC Current consumption
at rated voltage
Overcurrent protection at
input
PTC resettable fuse
XF204 + 2.64 W 110 mA 1.1 A / 33 V
X208 + 3.84 W 160 mA 0.6 A / 60 V
XF208 + 3.12 W 130 mA 1.1 A / 33 V
X216 + 5.76 W 240 mA 1.1 A / 33 V
X224 + 8.40 W 350 mA 1.1 A / 33 V
X204-2 + 6.36 W 265 mA 0.6 A / 60 V
XF204-2 + 5.28 W 220 mA 1.1 A / 33 V
X206-1 + 5.28 W 220 mA 0.6 A / 60 V
XF206-1 + 4.08 W 170 mA 1.1 A / 33 V
X212-2 + 7.92 W 330 mA 1.1 A / 33 V
X204-2LD + 6.36 W 265 mA 0.6 A / 60 V
X206-1LD + 5.28 W 220 mA 0.6 A / 60 V
X212-2LD + 7.92 W 330 mA 1.1 A / 33 V
X202-2IRT + 6.0 W 300 mA 0.6 A / 60 V
X204IRT + 4.8 W 200 mA 0.6 A / 60 V
XF204IRT + 4.8 W 200 mA 0.6 A / 60 V
X204 IRT PRO + 4.8 W 200 mA 0.6 A / 60 V
X202-2P IRT PRO + 7.2 W 300 mA 1.1 A / 33 V
X201-3P IRT PRO + 7.92 W 330 mA 1.1 A / 33 V
X202-2P IRT + 7.2 W 300 mA 1.1 A / 33 V
X201-3P IRT + 8.4 W 350 mA 1.1 A / 33 V
X200-4P IRT + 9.6 W 400 mA 1.1 A / 33 V
