Siemens SCALANCE X-200 Series User Manual

Technical Specifications
7.1 Technical specifications
SCALANCE X-200
98 Compact Operating Instructions, 12/2010, A5E00813159-11
Table 7- 4 Optical data
Device type
SCALANCE
Optical transmit power Receiver sensitivity
X204-2, XF204-2
X206-1, XF206-1
X212-2
X202-2IRT
-19 / -17 / -14 dBm
(min. / typ. / max.)
-34 / -32 dBm
(typ. / max.)
X204-2LD
X206-1LD
X212-2LD
-15 / -7 dBm
(min. / max)
-34 dBm
(max.)
X202-2P IRT PRO
X201-3P IRT PRO
X202-2P IRT
X201-3P IRT
X200-4P IRT
-8 / -4.5 / -2 dBm
(min. / typ. / max.)
-23 / -25 dBm
(min. / typ.)
Table 7- 5 Signaling contact
Device type
SCALANCE
Voltage at signaling contact Current through signaling contact
XF204 24 VDC max. 100 mA
X208 24 VDC max. 100 mA
XF208 24 VDC max. 100 mA
X216 24 VDC max. 100 mA
X224 24 VDC max. 100 mA
X204-2 24 VDC max. 100 mA
XF204-2 24 VDC max. 100 mA
X206-1 24 VDC max. 100 mA
XF206-1 24 VDC max. 100 mA
X212-2 24 VDC max. 100 mA
X204-2LD 24 VDC max. 100 mA
X206-1LD 24 VDC max. 100 mA
X212-2LD 24 VDC max. 100 mA
X202-2IRT 24 VDC max. 100 mA
X204IRT 24 VDC max. 100 mA
XF204IRT 24 VDC max. 100 mA
X204 IRT PRO 24 VDC max. 100 mA
X202-2P IRT PRO 24 VDC max. 100 mA
X201-3P IRT PRO 24 VDC max. 100 mA
X202-2P IRT 24 VDC max. 100 mA
X201-3P IRT 24 VDC max. 100 mA
X200-4P IRT 24 VDC max. 100 mA
