Description
3.4 Parameterization
7KT multimeter
Manual, 08/2018, 2514284149-01
29
The description of the parameters visible on the display can deviate from the details in the
table in some cases due to the restricted number of available characters. The parameter
code is the most reliable means of reference.
M01 General
Unit
Default
Range
P01.01 Primary current of the cur-
rent transformer
A 5 1 … 10000
P01.02 Secondary current of the
current transformer
A 5 1 … 5
P01.03
Nominal voltage
V
400
50 … 500000
P01.04 Rated power – OFF
• OFF
• ON
P01.05 Nominal voltage of primary
winding of voltage trans-
former
V 100 50 … 500000
P01.06 Nominal voltage of second-
ary winding of voltage trans-
former
V 100 50 … 500
P01.07 Wiring configuration – L1-L2-L3-N
• L1-L2-L3-N
• L1-L2-L3
• L1-L2-L3-N BIL
• L1-L2-L3 BIL
• L1-N-L2
• L1-N
P01.04
•
ON: Voltage transformers are used.
•
OFF: The next two parameters will be ignored.
P01.07
Set in accordance with the selected connection diagram.
