6.4 Modbus address register for devices with Modbus interface
7KT multimeter
Manual, 08/2018, 2514284149-01
53
Address
Number of
registers
Measured variable
Unit
Format
0058H
2
L3 voltage THD
005AH 2 L1 current THD
005CH
2
L2 current THD
005EH
2
L3 current THD
0060H
2
L1-2 voltage THD
0062H
2
L2-3 voltage THD
0064H
2
L3-1 voltage THD
0070H
2
KW L1-2
W/100
0072H
2
KW L2-3
0074H
2
KW L3-1
Address
Number of
registers
Measured variable
Unit
Format
Max. measured variables (HI)
0400H
2
L1 phase voltage
V/100 Unsigned long
0402H
2
L2 phase voltage
…
0462H
2
L3-1 voltage THD
%/100
Min. measured variables (LO)
0600H
2
L1 phase voltage
V/100 Unsigned long
0602H
2
L2 phase voltage
…
0662H
2
L3-1 voltage THD
%/100
…
Average measured variables (AV)
0800H 2 L1 phase voltage V/100 Unsigned long
0802H
2
L2 phase voltage
…
0862H
2
L3-1 voltage THD
%/100
Max. demand values of measured variables (MD)
0A00H
2
L1 phase voltage
V/100 Unsigned long
0A02H
2
L2 phase voltage
…
0A62H
2
L3-1 voltage THD
%/100
